SFV5R-2STE1HLF — Amphenol product photo
Amphenol

SFV5R-2STE1HLF – Amphenol ICC (FCI) 5-Pos 0.50mm FFC/FPC

MPNSFV5R-2STE1HLF
Active

Amphenol ICC (FCI) SFV-R series, 5-position, 0.50mm pitch, right-angle SMT FFC/FPC connector with ZIF flip-lock actuation, top contact, tin-plated terminals, rated 0.5A at 50V.

$0.5700Ref. price · indicative, final on quote
SFV5R-2STE1HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

SFV5R-2STE1HLF Technical Specifications
ParameterValue
SeriesSFV-R
Mounting typeSurface Mount, Right Angle
Cable end typeNotched or Tabbed
Flat flex typeFFC, FPC
Connector (Contact type)Contacts, Top
Voltage rating50V
Current rating0.5A
Operating temperature-55°C~105°C
Housing colorBlack
Actuator colorBlack
Contact materialPhosphor Bronze
Housing materialPolyamide (PA), Nylon, Glass Filled, Halogen Free
Actuator materialPolyphenylene Sulfide (PPS), Glass Filled, Halogen Free
Height above board0.071\" (1.80mm)
Material flammability ratingUL94 V-0
Pitch0.020\" (0.50mm)
PackageTape & Reel (TR); Cut Tape (CT)
FeaturesSolder Retention, Zero Insertion Force (ZIF)
TerminationSolder
Mating cycles20
Contact finishTin
Locking featureFlip Lock
FFC, FCB thickness0.30mm
Positions5

Product details

0.50 mm Pitch, 5 Positions, Top-Contact ZIF

The SFV5R-2STE1HLF: The top-contact design means the FPC conductor pads face upward when mated; the flip-lock actuator clamps the cable without insertion force, then locks to hold the cable against vibration.

SMT Right-Angle Mount, 1.80 mm Height Above Board

The mated height above board is 1.80 mm, which keeps the connector low-profile for stacking under a cover or display assembly.

Position Count Delta: 5 vs 8 vs 10

The SFV5R-2STE1HLF (5 positions) is the smallest circuit count in the SFV-R sibling set. The choice is purely a circuit-count decision for the BOM.
