TS03515A0000G terminal block plug, 02-508 series, 3 positions, 0.200" (5.08mm) pitch, 12 A, 300 V, tin-plated female sockets, free-hanging (in-line), screw - rising cage clamp termination.
| Parameter | Value |
|---|---|
| Type | Plug, Female Sockets |
| Series | 02-508 |
| Mounting | Free Hanging (In-Line) |
| Voltage - UL | 300 V |
| Current - UL | 12 A |
| Plug wire entry | 90° |
| Wire strip length | 6-7mm |
| Wire gauge or range - AWG | 12-24 AWG |
| Wire gauge or range - mm2 | 1-2.5mm² |
| Operating temperature | -40°C ~ 115°C |
| Color | Green |
| Contact material | Copper Alloy |
| Parameter | Value |
|---|---|
| Housing material | Thermoplastic Resin |
| Insulation height | 1.024\" (26.01mm) |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.200\" (5.08mm) |
| Package | Bulk |
| Features | Retention Latches (Wire Side) |
| Screw size | M3 |
| Torque - screw | 0.4 Nm (3.5 Lb-In) |
| Number of levels | 1 |
| Termination style | Screw - Rising Cage Clamp |
| Positions | 3 |
| Positions per level | 3 |
| Contact mating finish | Tin |
The TS03515A0000G is the 3-position member of the 02-508 series terminal block plug line, using a screw-rising cage clamp for wire termination. It is rated 12 A at 300 V with tin-plated female sockets and accepts 12-24 AWG (1-2.5 mm²) wire.
Retention latches on the wire side hold the plug in the mating header, and the green thermoplastic housing carries a UL94 V-0 flammability rating.
It accepts 12-24 AWG (1-2.5 mm²) wire.
Yes, it is RoHS3 compliant.
