Bulgin PX series IEC 320-C14 power entry module, order code PX0575/15/48, 3 positions, 10 A at 250 VAC, unfiltered commercial, quick-connect 0.189" (4.8 mm) termination, panel mount snap-in, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | PX |
| Filter type | Unfiltered - Commercial |
| Mounting | Panel Mount, Snap-In |
| Connector type | IEC 320-C14 |
| Voltage rating - appliance inlet | 250VAC |
| Current rating - appliance inlet | 10A |
| Panel cutout | Rectangular - 27.40mm x 19.80mm |
| Material flammability rating | UL94 V-0 |
| Approval agency | CCC, CSA, ENEC, UL, VDE |
| Package | Bulk |
| Termination | Quick Connect - 0.189\" (4.8mm) |
| Panel thickness | 0.059\" (1.50mm) |
| Accomodates a fuse | No |
| Positions | 3 |
The PX0575/15/48 is a Bulgin PX series IEC 320-C14 power entry module, 3 positions, rated 10 A at 250 VAC for unfiltered commercial duty. Termination is quick-connect 0.189" (4.8 mm) tabs; the housing mounts via snap-in into a rectangular panel cutout 27.40 mm x 19.80 mm, accepting panel thickness 0.059" (1.50 mm).
The PX0575/15/48 is ROHS3 compliant and carries approvals from CCC, CSA, ENEC, UL, and VDE.
