Bulgin PX0690/28

Bulgin PX0690/28 IEC 320-C18 Power Entry Module, 10A 250VAC

MPN PX0690/28
Active

Bulgin PX series power entry module, order code PX0690/28, IEC 320-C18 receptacle, 3 positions, 10 A at 250 VAC, panel mount flange, solder termination, unfiltered commercial type, UL94 V-0 housing.

$2.9800 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesPX
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

PX0690/28 specifications
ParameterValue
SeriesPX
Filter typeUnfiltered - Commercial
MountingPanel Mount, Flange
Connector typeIEC 320-C18
Voltage rating - appliance inlet250VAC
Current rating - appliance inlet10A
Panel cutoutVariable Size
Material flammability ratingUL94 V-0
Approval agencyCSA, ENEC, UL, VDE
PackageBulk
FeaturesFront or Rear Side Mount
TerminationSolder
Accomodates a fuseNo
Positions3

Product details

Panel-mount IEC inlet, solder termination

The PX0690/28 is a 3-position IEC 320-C18 receptacle from Bulgin's PX series, rated 10 A at 250 VAC with solder termination and a panel-mount flange. The unfiltered commercial inlet accepts front or rear side mounting and carries CSA, ENEC, UL, and VDE approvals. Housing material is rated UL94 V-0.

MPN
PX0690/28
