CNC Tech — IC & Device Sockets

CNC Tech IC & Device Sockets — 19 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Number of Positions or Pins (Grid)
6 (2 x 3) · 18 (2 x 9) · 8 (2 x 4) · 14 (2 x 7)
Base Product Number
210-1 · 211-1 · 232 · 243
Contact Finish Thickness - Mating
- · 10.0µin (0.25µm) · 100.0µin (2.54µm) · 60.0µin (1.52µm)
Contact Finish Thickness - Post
200.0µin (5.08µm) · 100.0µin (2.54µm) · 60.0µin (1.52µm)
Housing Material
Polybutylene Terephthalate (PBT) · Polyphenylene Sulfide (PPS), Glass Filled · Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type
Through Hole · Surface Mount · Through Hole, Kinked Pin
Termination Post Length
0.110" (2.78mm) · - · 0.124" (3.15mm)
Type
DIP, 0.3" (7.62mm) Row Spacing · PLCC · DIP, 0.6" (15.24mm) Row Spacing
