Conec 320X10559X
MPN320X10559X
Active
DSUB GENDER CHANGER DB25F DB25F
$8.53Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Free Hanging (In-Line) |
| Voltage rating | 125 V |
| Current rating | 7.5 A |
| IP rating | IP20 |
| Connector type | Gender Changer |
| Operating temperature | -55°C ~ 125°C |
| Housing color | Yellow |
| Shell material, finish | Steel, Tin Plated |
| Material flammability rating | UL94 V-0 |
| Package | Tray |
| Includes | 5 pcs - 1 Connector, 4 Jack Screws |
| Contact finish | Gold |
| Rows | 2 |
| Contact finish thickness | 8.00µin (0.203µm) |
| Convert to (Adapter end) | D-Sub, 25 Pin Female |
| Convert from (Adapter end) | D-Sub, 25 Pin Female |
