Ribbon Cable IDC Receptacle, 20 Circuits
The HARTING 09185207803800 is a 20-position IDC receptacle from the SEK series, built for mass-termination to 26-28 AWG ribbon cable. The free-hanging (in-line) housing lets the cable route directly into an enclosure without a board mount, and the polarizing key prevents a reversed mate against the matching header.
The 16-position 0918516781358U (with strain relief) is another alternative if the harness requires a cable pull-relief feature. The position count is the primary selection axis here — the pitch, wire gauge range, and IDC termination method are identical across all four.
Mating and Harness Fit
The IDC termination requires a mass-termination press to punch the contacts through the ribbon cable insulation in one stroke; individual crimping is not possible here. The feed-through feature in the housing allows the cable to pass straight through the connector body rather than terminating at an end wall, which simplifies daisy-chaining in a harness.
