HARTING Han® PushPull DisplayPort, Mini receptacle, order code 09455511000, 20 contacts, 0.5 A, 30 V, gold-plated contacts, surface-mount right-angle, solder termination, IP65/IP67.
| Parameter | Value |
|---|---|
| Series | Han® PushPull |
| Mounting | Surface Mount, Right Angle; Through Hole |
| Connector type | DisplayPort, Mini |
| Voltage - rated | 30V |
| Current rating | 0.5A |
| Positions | 20 |
| IP rating | IP65/IP67 - Dust Tight, Water Resistant, Waterproof |
| Mounting feature | Horizontal |
| Operating temperature | -40°C ~ 80°C |
| Insulation color | Black |
| Material flammability rating | UL94 V-0 |
| Gender | Receptacle |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Board Guide |
| Termination | Solder |
| Mating cycles | 100 |
| Contact finish | Gold |
| Number of ports | 1 |
The 09455511000 is HARTING's 20-contact Han® PushPull mini DisplayPort receptacle, sealed to IP65/IP67 when mated.
The 09455511000 shares the same 20-contact count, gold finish, and IP65 rating with the 9455511000 — the only difference is the package: Tape & Reel with Cut Tape (CT) vs Tape & Reel with Digi-Reel®.
Receptacle, mini DisplayPort, part of the Han® PushPull series.
