HARTING D-Sub receptacle, 15 positions, 2 rows, right-angle through-hole, 6.5A, stamped signal contacts, board lock, 4-40 flange, UL94 V-0.
| Parameter | Value |
|---|---|
| Type | Signal |
| Mounting | Through Hole, Right Angle |
| Connector type | Receptacle, Female Sockets |
| Current rating | 6.5A |
| Contact form | Stamped |
| Shell size, connector layout | 2 (DA, A) |
| Operating temperature | -55°C ~ 125°C |
| Contact material | Copper Alloy |
| Dielectric material | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled |
| Shell material, finish | Steel |
| Material flammability rating | UL94 V-0 |
| Package | Bulk |
| Features | Board Lock |
| Termination | Solder |
| Flange feature | Housing/Shell (4-40) |
| Rows | 2 |
| Backset spacing | 0.409\" (10.40mm) |
| Positions | 15 |
The HARTING 09662566612 is a 15-position D-Sub receptacle with female sockets, laid out in the DA (size 2) shell pattern — the standard footprint for a 15-pin D-Sub.
This receptacle includes a board lock feature. The flange uses 4-40 threaded inserts.
