HARTING 14011113101000
MPN14011113101000
Active
TERM BLK 11P TOP ENT 2.54MM SMD
$3.71Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Serieshar-flexicon®
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | har-flexicon® |
| Mounting | Surface Mount |
| Voltage | 160 V |
| Current | 6 A |
| Wire gauge | 20-26 AWG |
| Wire termination | Screwless - Spring Cage, Tension Clamp |
| Operating temperature | -40°C ~ 125°C |
| Color | Black |
| Housing material | Liquid Crystal Polymer (LCP), Glass Filled |
| Contact material - plating | Copper Alloy - Tin Plated |
| Pitch | 0.100\" (2.54mm) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Board Guide, Solder Retention |
| Number of levels | 1 |
| Mating orientation | Vertical with Board |
| Positions per level | 11 |
