HARTING 14121017001000
MPN14121017001000
Active
TERM BLOCK HDR 10POS VERT 5.08MM
$6.2300Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Serieshar-flexicon®
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Header, Male Pins, Shrouded (4 Side) |
| Series | har-flexicon® |
| Mounting | Through Hole |
| Voltage - UL | 600 V |
| Current - UL | 15 A |
| Operating temperature | -40°C ~ 110°C |
| Color | Black |
| Contact material | Copper Alloy |
| Housing material | Polyamide (PA), Nylon, Polyphthalamide (PPA) |
| Insulation height | 0.472\" (12.00mm) |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.200\" (5.08mm) |
All specifications
| Parameter | Value |
|---|---|
| Package | Bulk |
| Number of levels | 1 |
| Termination style | Solder |
| Header orientation | Vertical |
| Positions | 10 |
| Positions per level | 10 |
| Contact mating finish | Tin |
