0.80mm-Pitch Discrete-Wire Plug for Tight Harness Routing
The Hirose 3240-12P-TO-C(50) is a 12-position plug from the 3200 series, designed for discrete wire termination in free-hanging (in-line) harness assemblies.
Hirose 3240-12P-TO-C(50) 12-Position Plug, 0.80mm Pitch
MPN3240-12P-TO-C(50)
Active
Hirose 3200 series plug, 3240-12P-TO-C(50), 12 positions, 1 row, 0.031" (0.80mm) pitch, gold contacts, solder termination, free-hanging, black, tray.
$5.7300Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | 3200 |
| Wire type | Discrete |
| Type | Outer Shroud Contact |
| Mounting | Free Hanging (In-Line) |
| Connector type | Plug |
| Cable termination | Solder |
| Color | Black |
| Pitch | 0.031\" (0.80mm) |
| Package | Tray |
| Contact finish | Gold |
| Rows | 1 |
| Positions | 12 |
Product details
Frequently asked questions
What is the mating connector for the 3240-12P-TO-C(50)?
The 3240-12P-TO-C(50) is a plug with outer shroud contacts. It mates with the matching 3200 series receptacle — confirm the receptacle order code against your harness design.
