Hirose Electric Co Ltd BNC(75)-BPJ-1.5CV-(P)(40) — RF / Coaxial Connectors
Hirose Electric Co Ltd

Hirose BNC(75)-BPJ-1.5CV-(P)(40) 75 Ohm BNC Jack

MPNBNC(75)-BPJ-1.5CV-(P)(40)
Active

Hirose BNC series 75 Ohm BNC bulkhead jack, female socket, BNC(75)-BPJ-1.5CV-(P)(40), panel mount with front-side nut, solder termination, nickel body, gold-plated beryllium copper center contact, 500 mating cycles, 2 GHz max frequency.

$20.1500Ref. price · indicative, final on quote
BNC(75)-BPJ-1.5CV-(P)(40) datasheet
StockContact for availability
Lead time3-5 Days wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

BNC(75)-BPJ-1.5CV-(P)(40) Technical Specifications
ParameterValue
MountingPanel Mount
Connector typeJack, Female Socket
Fastening typeBayonet Lock
Voltage rating150 V
Frequency - max2 GHz
Mounting featureBulkhead - Front Side Nut
Cable group1.5C-2V
Operating temperature-30°C ~ 60°C
Body materialBrass
Housing colorSilver
Dielectric materialPolytetrafluoroethylene (PTFE)
Center contact materialBeryllium Copper
PackageBulk
Includes3 pcs - 1 Connector, 1 Nut, 1 Washer
Impedance75 Ohms
Body finishNickel
Mating cycles500
Number of ports1
Shield terminationSolder
Contact terminationSolder
Center contact platingGold

Product details

75 Ohm BNC Bulkhead Jack for 1.5C-2V Coax

The BNC(75)-BPJ-1.5CV-(P)(40): The connector ships as three pieces: the BNC jack body, a mounting nut, and a washer, all needed for the front-side bulkhead install. Rated to 2 GHz maximum frequency, this jack covers the full video band and L-band satellite IF without a problem. The 75 Ohm impedance is set by the PTFE dielectric and the 1.5C-2V cable geometry — swap cable types and the impedance match drifts, so stick with the listed cable group.

No crimp tool needed, just a soldering iron and the 1.5C-2V cable prepped to the right strip length.

Frequently asked questions

Where can I buy BNC(75)-BPJ-1.5CV-(P)(40) and how is it quoted?

Submit an RFQ for your volume and target price.

Is BNC(75)-BPJ-1.5CV-(P)(40) 50 ohm or 75 ohm?

75 Ohms — confirmed by the spec. Do not use it in a 50 Ohm system; the impedance mismatch will cause signal reflections and loss.

What cable does BNC(75)-BPJ-1.5CV-(P)(40) work with?

It's designed for 1.5C-2V coaxial cable. The center contact and shield are both solder-terminated, so you need to prep the cable to the correct strip length for the solder cups. Using a different cable type will change the impedance and may cause poor termination.

Does BNC(75)-BPJ-1.5CV-(P)(40) come with mounting hardware?

Yes — the package includes three pieces: the connector body, one mounting nut, and one washer. That's everything needed for a front-side bulkhead panel mount.
