Hirose BWA series between-series adapter, BNC(75)J-H.FLJ-BPA(40), BNC jack to H.FL jack, 75 Ohm impedance, 3 GHz max, straight body, panel mount bulkhead, nickel brass body, gold-plated beryllium copper center contacts, includes lockwasher and nut.
| Parameter | Value |
|---|---|
| Series | BWA |
| Adapter type | Jack to Jack |
| Mounting | Panel Mount |
| Adapter series | BNC to H.FL |
| Fastening type | Bayonet Lock, Snap-On |
| Conversion type | Between Series |
| Frequency - max | 3 GHz |
| Mounting feature | Bulkhead |
| Operating temperature | -40°C ~ 85°C |
| Body material | Brass |
| Dielectric material | Polytetrafluoroethylene (PTFE) |
| Center contact material | Beryllium Copper |
| Parameter | Value |
|---|---|
| Style | Straight |
| Package | Bulk |
| Includes | 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut |
| Impedance | 75 Ohms |
| Body finish | Nickel |
| Center gender | Female to Male |
| Center contact plating | Gold |
| Convert to (Adapter end) | H.FL Jack, Male Pin |
| Convert from (Adapter end) | BNC Jack, Female Socket |
The Hirose BNC(75)J-H.FLJ-BPA(40) is a between-series adapter that converts a BNC jack (female socket) to an H.FL jack (male pin).
The body is machined brass with a nickel finish — standard for BNC hardware that sees moderate environmental exposure. This is a panel-mount bulkhead adapter, so it anchors to the chassis and the H.FL cable connects on the inside.
Yes, the package includes three pieces: the connector body, one lockwasher, and one nut. No additional hardware is needed for a standard bulkhead panel mount.
