Hirose Electric Co Ltd DH-27-CV2B

Hirose DH-27-CV2B Backshell, 27-Pos, 180°, Shielded

MPN DH-27-CV2B
Active

Hirose DH series two-piece backshell and cover, DH-27-CV2B, 27 positions, 180° cable exit, shielded metal shell with steel/plastic cover, M2.3 mating screw feature, tray package.

$10.3800 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesDH
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

DH-27-CV2B specifications
ParameterValue
SeriesDH
Cable typeRound
Accessory typeTwo Piece Backshell and Cover
Cable exit180°
ColorBlack
MaterialMetal Shell, Steel/Plastic Cover
Primary materialMetal
PackageTray
FeaturesMating Screw M2.3
HardwareAssembly Hardware
ShieldingShielded
Positions27

Product details

What This Backshell Does in the DH Series

The Hirose DH-27-CV2B is a two-piece backshell and cover designed to terminate a 27-position DH series circular connector assembly. This backshell is the strain-relief and EMI-shielding termination point for round cable harnesses using the DH series.

Position Count and Cable Exit — Fit Check

The 27-position count is the first thing to match against your connector. This backshell fits a 27-contact DH series plug or receptacle — no more, no fewer. The 180° cable exit means the cable runs straight back from the connector body, not at a right angle. That matters when you're routing inside a panel or enclosure where a 90° exit would interfere with a wall or adjacent component.

Shielding and Hardware — What You Get and What You Don't

The metal shell provides 360° shielding around the cable termination — useful for signal integrity in electrically noisy environments. The assembly hardware is present (the screw posts and cover), but the M2.3 mating screws themselves are a feature of the design, not included hardware. You'll need to source M2.3 screws separately to secure the backshell to the connector. The cover is a steel/plastic composite, giving a balance of mechanical strength and weight.
