USB Mini B Receptacle for Board-Edge Integration
The Hirose UX60SC-MB-5S8 is a 5-contact USB mini B receptacle from the UX series, specified for USB 2.0 applications. It mounts horizontally via surface-mount right-angle termination, with solder retention features that anchor the connector against the mechanical stress of repeated USB plug insertions.
Last Buy — Plan Your Final Procurement
The UX60SC-MB-5S8 carries a Last Buy lifecycle status. This means Hirose has scheduled end-of-production; remaining stock is finite. For ongoing production, secure your lifetime buy quantity now.
This is a standard USB mini B receptacle — it mates with any USB mini B plug cable. The 5 contacts carry USB 2.0 differential pairs plus ID and power. Mounting is SMT right-angle, horizontal to the board edge. Solder retention pads on the connector body take the mechanical load from cable insertion and removal, protecting the signal solder joints.
