Hirose Electric Co Ltd — Female Socket Headers

Hirose Electric Co Ltd Female Socket Headers — 48 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Base Product Number
3260 · A3-12DA · A3-14DA · A3-16DA
Number of Positions
10 · 8 · 12 · 14
Insulation Height
0.114" (2.90mm) · 0.234" (5.95mm) · 0.165" (4.20mm) · 0.035" (0.90mm)
Current Rating (Amps)
500mA · 2A · 1A · 0.3A Signal, 4A Power
Operating Temperature
-30°C ~ 85°C · -55°C ~ 85°C · -55°C~85°C · -35°C ~ 85°C
Voltage Rating
125VAC · 250V · 200VAC · 50V
Pitch - Mating
0.031" (0.80mm) · 0.079" (2.00mm) · - · 0.016" (0.40mm)
Contact Finish Thickness - Post
1.25µin (0.032µm) · 78.7µin (2.00µm) · 39.4µin (1.00µm) · Flash
