JAE Electronics DB-25PR — D-Sub Cable Assemblies

JAE DB-25PR D-Sub Plug, 25-Pin Male, Solder Cup, 5A

MPNDB-25PR
Active

JAE DB series D-Sub plug, 25 positions, 2 rows, male pins, solder cup termination, gold contact finish, panel mount, steel shell with clear chromate, 5A rated, -55°C to 105°C.

$8.3400Ref. price · indicative, final on quote
JAE Electronics DB-25PR datasheet (PDF)
RoHSRoHS Compliant
SeriesDB
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

DB-25PR specifications
ParameterValue
SeriesDB
TypeSignal
MountingPanel Mount
Connector typePlug, Male Pins
Current rating5A
Wire gauge20 AWG
Shell size, connector layout3 (DB, B)
Operating temperature-55°C~105°C
ColorWhite
Contact materialCopper Alloy
Dielectric materialPolyamide (PA), Nylon, Glass Filled
Shell material, finishSteel, Clear Chromate Plated Zinc
PackageBag
TerminationSolder Cup
Contact finishGold
Flange featureHousing/Shell (Unthreaded)
Rows2
Positions25

Product details

25-Pin D-Sub Plug for Cable Harness Assembly

The JAE DB-25PR is a 25-position D-Sub plug with male pins, built for terminating cable assemblies via solder cups. It's the male half of a standard DB-25 interconnect — mates with the DB-25SR receptacle (female sockets) for a full shielded pair.

What the 5 A Rating and Temperature Range Mean for Your Build

The glass-filled polyamide dielectric holds its shape through wave solder and field rework.

Solder Cup Termination and Panel Mounting

Termination is solder cup — you strip 20 AWG wire, tin it, and solder into the cup on the back of each pin. No crimp tool needed, which makes field repair straightforward, but it does mean each joint is manual and takes time on a 25-position connector. The shell itself is steel with clear chromate — it grounds through the mounting hardware and the mating interface, so make sure your panel bond is clean.

Frequently asked questions

What is the mating female connector for DB-25PR?

The mating female receptacle is the DB-25SR, a 25-position D-Sub with female sockets, same shell size (3/DB/B), gold contacts, and solder cup termination. They mate directly.

Is DB-25PR RoHS compliant?

Yes, the DB-25PR is listed as RoHS Compliant, so it meets the EU Restriction of Hazardous Substances directive for lead, mercury, cadmium, and other restricted materials.

Does DB-25PR have a metal shell?

Yes, the shell is steel with a clear chromate plated zinc finish. It provides basic EMI shielding and corrosion resistance for panel-mount or cable applications.
