The B11B-PH-SM4-TB: This is an 11-position, single-row header on 2.00mm pitch — the pitch is the dimension that sets the pad spacing on your board, not a generic 'compact' claim.
JST Sales America Inc., PH series, Board to Cable/Wire, Header, Male Pin, 11 Positions, 0.079" (2.00mm) Pitch, Surface Mount, Shrouded - 4 Wall, Detent Lock, Solder Retention, 2A, 100V, UL94 V-0, Natural
$1.3500Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | PH |
| Gender | Male Pin |
| Mounting type | Surface Mount |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 100V |
| Current rating | 2A |
| Operating temperature | -25°C ~ 85°C |
| Contact material | Copper Alloy |
| Insulation color | Natural |
| Insulation height | 0.260\" (6.60mm) |
| Insulation material | Polyamide (PA6T), Nylon 6T |
| Mated stacking heights | 8.6mm |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 11 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.130\" (3.30mm) |
Product details
Frequently asked questions
Is B11B-PH-SM4-TB RoHS compliant?
No — this part is listed as RoHS non-compliant. If your BOM requires RoHS compliance, the closest functional alternative is B11B-PH-SM4-TB(LF)(SN), which shares the same pitch, position count, and shroud but is RoHS-compliant.
What is the pitch of B11B-PH-SM4-TB?
The mating pitch is 0.079" (2.00mm), single row.
What does B11B-PH-SM4-TB mate with?
This is a male pin header from the JST PH series, designed to mate with a PH-series crimp receptacle housing (sold separately). The detent lock engages with the matching housing latch.
