Keystone Electronics PCB pin receptacle, order code 1419-2, accepts 0.032" ~ 0.046" pin diameter, gold-plated beryllium copper contact, swage termination, no tail, 0.200" socket depth, 0.125" flange diameter, bulk packaging.
| Parameter | Value |
|---|---|
| Tail type | No Tail |
| Mounting hole diameter | 0.069\" (1.75mm) |
| Socket depth | 0.200\" (5.08mm) |
| Contact material | Beryllium Copper |
| Package | Bulk |
| Termination | Swage |
| Contact finish | Gold |
| Flange diameter | 0.125\" (3.18mm) |
| Length - overall | 0.324\" (8.23mm) |
| Accepts pin diameter | 0.032\" ~ 0.046\" (0.81mm ~ 1.17mm) |
| Contact finish thickness | 10.0µin (0.25µm) |
The 1419-2 is a swage-terminated PCB pin receptacle from Keystone Electronics, designed to accept pin diameters from 0.032" to 0.046" (0.81 mm to 1.17 mm).
The specified mounting hole diameter is 0.069" (1.75 mm). The no-tail swage termination presses into the plated-through hole and is swaged on the opposite side for a permanent mechanical and electrical connection.
The 1419-2 accepts pin diameters from 0.032" to 0.046" (0.81 mm to 1.17 mm).
