Keystone Electronics TO-3 transistor socket, order code 4600, 3 positions oval grid, closed frame, tin-plated brass contacts, chassis mount, solder termination, polyester glass-filled housing, UL94 V-0.
| Parameter | Value |
|---|---|
| Type | Transistor, TO-3 |
| Mounting | Chassis Mount |
| Housing material | Polyester, Glass Filled |
| Contact material - post | Brass |
| Contact material - mating | Brass |
| Material flammability rating | UL94 V-0 |
| Package | Bulk |
| Features | Closed Frame |
| Termination | Solder |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Number of positions or pins | 3 (Oval) |
The 4600 is Keystone Electronics' TO-3 transistor socket, a 3-position oval-grid closed-frame design for chassis-mount applications.
Termination is solder to the chassis-mount posts; the closed frame protects the transistor leads during handling and insertion.
It is a TO-3 transistor socket with 3 positions on an oval grid.
