Mill-Max Manufacturing Corp. 802-10-010-10-001000 — Pin Headers

Mill-Max Manufacturing Corp. 802-10-010-10-001000

MPN802-10-010-10-001000
Active

CONN HEADER VERT 10POS 2.54MM

$2.0400Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Series802
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

802-10-010-10-001000 key specifications
ParameterValue
Series802
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typePush-Pull
Contact materialBrass Alloy
Insulation colorBlack
Insulation height0.110\" (2.79mm)
Insulation materialPolycyclohexylenedimethylene Terephthalate (PCT)
StyleBoard to Board
PackageBulk
ShroudingUnshrouded

All specifications

802-10-010-10-001000 additional specifications
ParameterValue
TerminationSolder
Contact shapeCircular
Rows2
Pitch0.100\" (2.54mm)
Positions10
Row spacing - mating0.100\" (2.54mm)
Contact finish - postGold
Contact length - post0.118\" (3.00mm)
Overall contact length0.438\" (11.12mm)
Contact finish - matingGold
Contact length - mating0.195\" (4.95mm)
Contact finish thickness - post10.0µin (0.25µm)
Contact finish thickness - mating10.0µin (0.25µm)
