Mill-Max 811 series spring-loaded piston connector, order code 811-22-005-30-000101, 5 contacts, single row, 0.100" (2.54mm) pitch, gold-plated copper alloy contacts, 20.0µin (0.51µm) finish, surface-mount solder termination, bulk packaging.
| Parameter | Value |
|---|---|
| Series | 811 |
| Mounting | Surface Mount |
| Connector type | Piston |
| Positions | 5 |
| Material | Copper Alloy |
| Pitch | 0.100\" (2.54mm) |
| Package | Bulk |
| Contact finish | Gold |
| Rows | 1 |
| Contact finish thickness | 20.0µin (0.51µm) |
The 811-22-005-30-000101 is the 5-contact member of Mill-Max's 811 series spring-loaded piston connectors, offering a single-row layout at 0.100" (2.54mm) pitch. Contacts are copper alloy with 20.0µin (0.51µm) gold finish, suited for repeated mating cycles in signal-level circuits.
