Mill-Max 814 series spring-loaded piston connector, order code 814-22-008-30-009101, 8 contacts, dual row, 0.100" (2.54mm) pitch, gold-plated contacts with 20.0µin (0.51µm) thickness, surface-mount solder termination, bulk packaging.
| Parameter | Value |
|---|---|
| Series | 814 |
| Mounting | Surface Mount |
| Connector type | Piston |
| Positions | 8 |
| Material | Copper Alloy |
| Pitch | 0.100\" (2.54mm) |
| Package | Bulk |
| Row spacing | 0.100\" (2.54mm) |
| Contact finish | Gold |
| Rows | 2 |
| Contact finish thickness | 20.0µin (0.51µm) |
The 814-22-008-30-009101 is an 8-contact member of Mill-Max's 814 spring-loaded piston connector series, arranged in a dual-row layout on 0.100" (2.54mm) pitch. Contacts are gold-plated to 20.0µin (0.51µm) over copper alloy, and the connector mounts via surface-mount solder terminations.
The 814-22-008-30-009101 is ROHS3 compliant.
