Molex 2004 Series 0003067044 – 4-Position Plug Housing, 3.68mm Pitch
It carries two rows on a 0.145" (3.68mm) pitch with matching row spacing, giving you a compact 2x2 layout that fits standard panel cutouts for the series. The polyamide 6/6 (PA66) insulation handles the thermal cycling and resists common shop fluids.
What Fits Into This Housing – Contacts and Mating Half
The housing accepts either male or female contacts, so the same shell works on both sides of the connection depending on which terminal you load. The mating half is the corresponding 2004 Series receptacle header — same 0.145" (3.68mm) pitch, same 2-row layout, same latch holder interface. The latch on the plug snaps over the ramp on the header; you hear it seat. No secondary lock needed for most applications, though the TPA (terminal position assurance) is handled by the contact design itself in this series.
Mounting and Termination – Panel Snap-In, Crimp Contacts
Mounting is panel mount, snap-in — the housing presses into a rectangular cutout in the panel or bulkhead and the integral barbs lock it in place. No separate retaining clip or nut required. The black color is standard for the series — no color-coding for keying in this variant. If you need a polarized mate, check the mating header's keying options in the same 2004 family.
