Molex 0010897082 — Pin Headers

Molex 0010897082 C-Grid 70280 Header, 8 Pos, 2.54mm Pitch

MPN0010897082
Active

Molex C-Grid 70280 series unshrouded breakaway header, 8 positions, 2.54mm pitch, gold-plated mating contacts, through-hole solder termination, black LCP housing, UL94 V-0.

$1.6600Ref. price · indicative, final on quote
Molex 0010897082 datasheet (PDF)
RoHSROHS3 Compliant
SeriesC-Grid 70280
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

0010897082 key specifications
ParameterValue
SeriesC-Grid 70280
TypeMale Pin
MountingThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.090\" (2.29mm)
Insulation materialLiquid Crystal Polymer (LCP), Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk

All specifications

0010897082 additional specifications
ParameterValue
ShroudingUnshrouded
TerminationSolder
ApplicationsAutomotive, General Purpose, Lighting, Medical, Telecommunications
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions8
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.107\" (2.71mm)
Overall contact length0.437\" (11.10mm)
Contact finish - matingGold
Contact length - mating0.240\" (6.10mm)
Contact finish thickness - post74.8µin (1.90µm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Board Layout and Current Ceiling

The 0010897082: The 0.107-inch post length fits standard 1.6 mm PCBs with enough tail for a reliable solder fillet.

Mating Cycle Life and Contact Interface

The tin-plated solder tails (74.8 µinch) handle the board-level connection without galvanic mismatch. Square male pins (0.025-inch square typical for C-Grid) mate with standard C-Grid crimp receptacles or IDC sockets.

Application Range and Compliance

Rated for automotive, general purpose, lighting, medical, and telecommunications environments.
