Board-to-board or cable header
The 0010897481 is the 48-position member of Molex's C-Grid 70280 breakaway header line, unshrouded, with a push-pull fastening style. It carries tin-plated mating contacts (150.0 µin / 3.81 µm thickness) on a 0.100" (2.54 mm) pitch, dual rows with 0.100" (2.54 mm) row spacing, and terminates through-hole with solder.
Position count and footprint
The 48-position 0010897481 sits at the high end of the C-Grid 70280 breakaway header series; the 0.100" (2.54 mm) pitch and dual-row footprint are shared across the series, so match the position count to the circuit count on the board.
