Molex C-Grid 70280 header, order code 0010897561, 56 positions, dual row, 0.100" (2.54 mm) pitch, tin-plated mating contacts, through-hole solder termination, unshrouded breakaway style, black LCP housing rated UL94 V-0.
Molex C-Grid 70280 0010897561 Header, 56-Pos 2.54mm
MPN0010897561
Active
Molex C-Grid 70280 header, order code 0010897561, 56 positions, dual row, 0.100" (2.54 mm) pitch, tin-plated mating contacts, through-hole solder termination, unshrouded breakaway style, black LCP housing rated UL94 V-0.
$5.6300Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | C-Grid 70280 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.090\" (2.29mm) |
| Insulation material | Liquid Crystal Polymer (LCP), Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | Automotive, General Purpose, Lighting, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 56 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.107\" (2.71mm) |
| Overall contact length | 0.437\" (11.10mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.240\" (6.10mm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
Product details
Frequently asked questions
What is the 0010897561's listed style?
The style is Board to Board or Cable — a dual-row male pin header in the C-Grid 70280 series rated for both board-to-board and cable interconnect paths.
What is the 0010897561's listed series?
It belongs to the C-Grid 70280 series from Molex, a standard 0.100 inch (2.54 mm) pitch dual-row header family.
