Molex KK254, 42377 series, 5-position single-row unshrouded header, 0.100" (2.54mm) pitch, right-angle through-hole, gold-plated male pins, UL94 V-0 black nylon housing.
| Parameter | Value |
|---|---|
| Series | KK254, 42377 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Insulation color | Black |
| Insulation height | 0.098\" (2.50mm) |
| Insulation material | Polyamide (PA), Nylon, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Parameter | Value |
|---|---|
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.324\" (8.23mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 0022288053: The breakaway design means you can snap the strip to exactly 5 positions — or any length from 1 to 40 — reducing inventory complexity across multiple BOM lines. Gold plating on the mating face (15.0µin) ensures reliable signal contact over repeated mating cycles, while the tin-plated posts (100.0µin) solder cleanly into plated through-holes.
The pitch is 0.100" (2.54mm) — standard for prototyping and dense signal routing.
No, it is unshrouded — the male pins are exposed for mating with a receptacle housing.
It mates with a KK254 series crimp receptacle housing (e.g., Molex 50-57-9405 or similar 5-position housing) using the matching crimp terminals.
