Molex 0026482031 — Pin Headers

Molex 0026482031 KK396 Header, 3 Pos, 3.96mm, Gold

MPN0026482031
Active

Molex KK396, 41661 series, 0026482031, Header, Breakaway, 3 Positions, 0.156" (3.96mm) Pitch, Through Hole, Gold Mating, Tin Post, UL94 V-0

$2.1000Ref. price · indicative, final on quote
Molex 0026482031 datasheet (PDF)
RoHSROHS3 Compliant
SeriesKK396, 41661
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

0026482031 key specifications
ParameterValue
SeriesKK396, 41661
TypeMale Pin
MountingThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialBrass
Insulation colorBlack
Insulation height0.128\" (3.25mm)
Insulation materialPolyester, Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk

All specifications

0026482031 additional specifications
ParameterValue
ShroudingUnshrouded
TerminationSolder
ApplicationsAutomotive, General Purpose, Industrial, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.156\" (3.96mm)
Positions3
Contact finish - postTin
Contact length - post0.172\" (4.37mm)
Overall contact length0.750\" (19.05mm)
Contact finish - matingGold
Contact length - mating0.450\" (11.43mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating20.0µin (0.51µm)

Product details

The Molex 0026482031 is a 3-position, single-row breakaway header from the KK396 and 41661 series. It mates with matching KK396 crimp receptacles or IDC connectors for board-to-board or cable-to-board links.

Through-Hole Mount and Unshrouded Profile

Through-hole termination with a 0.172" (4.37mm) post length and 0.450" (11.43mm) mating pin length. The unshrouded design keeps the profile low — insulation height is 0.128" (3.25mm) above the board — and allows the header to be broken to shorter lengths if needed.

Frequently asked questions

What is the pitch of Molex 0026482031?

The mating pitch is 0.156" (3.96mm), a standard KK396 footprint. The single-row, 3-position layout matches the board layout for a 3-circuit wire-to-board or board-to-board interconnect.

Is Molex 0026482031 shrouded or unshrouded?

Unshrouded — the header has no surrounding shroud, so the mating receptacle slides directly over the exposed pins. This keeps the board profile low and allows the header to be broken to shorter lengths.

Where can I buy Molex 0026482031?

Sourced to order against your BOM quantity. Availability and current pricing confirmed at quote time — submit an RFQ for this part number.
