The 0026482076: Single-row layout keeps the board footprint narrow — 7 positions span about 1.1" (28mm) edge-to-edge.
Contact Plating and Mating Duty
The posts are tin-plated at 100.0µinch for solderability. The friction lock provides basic retention against vibration — not a secondary TPA, but enough to keep the header mated in a fixed installation where the cable isn't routinely tugged.
ROHS3 compliant per the listed status.
Mates with Molex KK396 crimp receptacle housings (series 41672) using the 0.156" pitch terminal. The breakaway design allows depopulating unused positions — snap off the required length before soldering.
