Molex 0026482105

Molex 0026482105 KK396 Header – 10 Pos, 3.96mm Pitch

MPN 0026482105
Active

Molex KK396, 41671 series, 10-position single-row shrouded header, 0.156" (3.96mm) pitch, through-hole solder termination, gold-plated mating contacts, friction lock, UL94 V-0 black polyester housing.

$5.3900 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesKK396, 41671
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

0026482105 key specifications
ParameterValue
SeriesKK396, 41671
TypeMale Pin
MountingThrough Hole
Connector typeHeader, Breakaway
Fastening typeFriction Lock
Contact materialBrass
Insulation colorBlack
Insulation height0.500\" (12.70mm)
Insulation materialPolyester
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk

All specifications

0026482105 additional specifications
ParameterValue
ShroudingShrouded - 1 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Industrial, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.156\" (3.96mm)
Positions10
Contact finish - postTin
Contact length - post0.172\" (4.37mm)
Overall contact length0.750\" (19.05mm)
Contact finish - matingGold
Contact length - mating0.450\" (11.43mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating20.0µin (0.51µm)

Product details

10-Position Shrouded Header – KK396 Series Fit

This Molex 0026482105 is a 10-circuit, single-row shrouded header from the KK396 series, pitched at 0.156" (3.96mm). Friction lock on the header body keeps the mated pair engaged under vibration — useful in automotive, industrial, and medical equipment where the connector sees movement or shock. Tin plating on the solder tails (100.0µin) gives a reliable solder joint with standard through-hole processes.

Insulation height is 0.500" (12.70mm) above the board — check your enclosure clearance if the connector sits near a cover or another board.
