Molex KK396 0026614110 Header, 11-Pos, 3.96mm, Shrouded

MPN0026614110
Active

Molex KK396 header, order code 0026614110, 11 positions, single row, 0.156" (3.96 mm) pitch, through-hole solder termination, shrouded 1-wall friction-lock housing, gold-over-nickel mating contact (20 µin), tin post finish (100 µin), glass-filled polyester UL94 V-0 insulation.

$3.9900Ref. price · indicative, final on quote
0026614110 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

0026614110 Technical Specifications
ParameterValue
SeriesKK396, 41791
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typeFriction Lock
Insulation colorNatural
Insulation height0.446\" (11.33mm)
Insulation materialPolyester, Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk
ShroudingShrouded - 1 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Industrial, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.156\" (3.96mm)
Positions11
Contact finish - postTin
Contact length - post0.140\" (3.56mm)
Overall contact length0.720\" (18.29mm)
Contact finish - matingGold
Contact length - mating0.450\" (11.43mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating20.0µin (0.51µm)

Product details

11-circuit shrouded header with friction lock

The 0026614110 is the 11-circuit member of Molex's KK396 header line, a single-row shrouded header with a friction-lock housing for positive retention against cable pull. It carries gold-plated mating contacts (20.0 µin) and a tin-plated post finish (100.0 µin), mounts through-hole, and is rated UL94 V-0 on the glass-filled polyester insulation.
