Molex 0340620050 — Connector Housings

Molex MX150 0340620050 Receptacle Housing, 2 Pos, 5.00mm

MPN0340620050
Active

Molex MX150 34062 series receptacle housing, 2 positions, 5.00mm pitch, single row, gray, sealed with CPA, crimp termination, free hanging, active.

$1.9700Ref. price · indicative, final on quote
Molex 0340620050 datasheet (PDF)
RoHSROHS3 Compliant
SeriesMX150 34062
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

0340620050 specifications
ParameterValue
SeriesMX150 34062
TypeFemale Socket
MountingFree Hanging (In-Line)
Connector typeReceptacle
Fastening typeLatch Holder
Operating temperature-40°C ~ 155°C
ColorGray
Insulation materialPolyamide (PA6), Nylon 6
NoteContacts Not Included
Pitch0.197\" (5.00mm)
PackageBulk
FeaturesConnector Position Assurance (CPA), Sealed
Rows1
Contact terminationCrimp
Positions2

Product details

MX150 Sealed Housing for Harsh Environments

The housing is molded from polyamide (PA6 / Nylon 6) and carries the sealed designation, meaning the interface is designed to accept a mating plug with an integrated seal (typically an O-ring or gasket) to achieve an IP-rated connection when properly assembled.

Termination and Contact Ordering

The free-hanging (in-line) mounting style allows the housing to be used as a cable-side connector, mating with a corresponding header or plug that is panel-mounted or board-mounted. The single-row, 2-position layout at 5.00mm pitch provides generous spacing for power or signal circuits in a compact footprint.

Frequently asked questions

Is 0340620050 a sealed connector housing?

Yes, the housing is designated as sealed and includes a Connector Position Assurance (CPA) feature. When mated with the corresponding MX150 plug and properly terminated, the assembly achieves a sealed interface suitable for wet or dusty environments.

Does 0340620050 include terminals?

No. The housing ships without contacts. The female socket terminals must be ordered separately and crimped onto the wire before insertion into the housing.

What is the pitch and number of positions for 0340620050?

The housing has 2 positions arranged in a single row at a 5.00mm pitch.
