Molex 0397000202

Molex Eurostyle 0397000202, 2-Pos Terminal Block, 6 A, 150 V

MPN 0397000202
Active

Molex Eurostyle 39700 terminal block, 0397000202, 2 positions, 0.100" (2.54mm) pitch, 6 A, 150 V, through-hole, screwless push-button clamp, top entry, green housing.

$1.4900 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesEurostyle 39700
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

0397000202 specifications
ParameterValue
SeriesEurostyle 39700
MountingThrough Hole
Voltage150 V
Current6 A
Wire gauge18-26 AWG
Wire terminationScrewless - Push Button Clamp
Operating temperature-40°C ~ 105°C
ColorGreen
Housing materialPolyamide (PA66), Nylon 6/6
Clamp material - platingSteel, Stainless
Contact material - platingBrass - Tin Plated
Pitch0.100\" (2.54mm)
PackageBulk
Number of levels1
Mating orientationVertical with Board
Positions per level2

Product details

Two-Position Screwless Terminal Block for PCB Mount

The Molex 0397000202 is a 2-position Eurostyle 39700 terminal block designed for direct PCB mounting. It uses a screwless push-button clamp for wire termination, accepting 18-26 AWG wire. The green polyamide (PA66) housing is UL94 V-0 rated by extension of the series material, and the brass contacts are tin-plated for solderability and corrosion resistance in dry indoor use.

How the Push-Button Clamp Changes Field Wiring

Instead of a screw, the 0397000202 uses a push-button clamp: press the orange button to open the wire entry, insert the stripped conductor, release the button to clamp. This eliminates over-torque damage to the housing and speeds wiring compared to a screw-clamp block. The clamp material is stainless steel, so it resists corrosion in humid cabinet environments. Wire orientation is top entry — wires enter perpendicular to the PCB surface, which suits a board mounted flat in an enclosure with wiring routed above the board. The single-level layout keeps the profile low.

Position Count and Series Siblings

The 0397000202 is the 2-position member of the Eurostyle 39700 series. The same pitch and termination style is shared by the 3-position 0397000302 and the 1-position 0397000102. There is no difference in current rating, voltage rating, or wire range across the series.
