The Molex 0447641402 is a 14-position dual-row receptacle from the Micro-Fit 3.0 BMI 44764 series, designed for board-to-board or cable-to-board interconnect. Gold plating on the mating side of the phosphor bronze contacts (15.0 µ" / 0.38 µm) supports repeated mating cycles, while the tin-plated posts (100.0 µ" / 2.54 µm) solder cleanly into plated through-holes. The 14 circuits are fully loaded across two rows, giving a compact 3.00 mm × 3.00 mm grid that keeps the board footprint tight for a 5 A per circuit interconnect. The 600 VAC rating, combined with the 3.00 mm pitch and UL94 V-0 LCP housing, gives enough creepage for line-voltage isolation in general-purpose and telecommunications equipment.
Blind Mating and Board Guide
This receptacle includes integral board guides and a blind-mating feature — the housing geometry self-aligns with the mating header before the contacts engage.
The ROHS3 compliance covers the latest EU exemption revisions, so no regulatory hang-up for a BOM destined for European or North American assembly.
