Molex 0464379208 — Specialty Circular

Molex 0464379208 EXTreme Ten60Power Plug, 8 Pos, 60A

MPN0464379208
Active

Molex EXTreme Ten60Power 46437 plug, 8 positions, 1 row, male blades, 60 A per contact, 600 VAC/250 VDC, 5.50 mm pitch, press-fit through-hole right-angle, gold 30.0 µin, UL94 V-0, black, tray.

$12.8700Ref. price · indicative, final on quote
Molex 0464379208 datasheet (PDF)
RoHSROHS3 Compliant
SeriesEXTreme Ten60Power 46437
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

0464379208 specifications
ParameterValue
SeriesEXTreme Ten60Power 46437
MountingThrough Hole, Right Angle
Connector typeEXTreme Ten60Power
Voltage rating600VAC, 250VDC
Current rating60A per Contact
Operating temperature-40°C ~ 105°C
ColorBlack
Material flammability ratingUL94 V-0
Pitch0.217\" (5.50mm)
PackageTray
TerminationPress-Fit
Contact finishGold
Rows1
Positions8
Contact layout, typical8 Power
Contact finish thickness30.0µin (0.76µm)

Product details

Right-Angle Press-Fit Power Plug for Board-Edge Distribution

The Molex 0464379208 is an 8-circuit plug from the EXTreme Ten60Power 46437 series, carrying male blades in a single row at a 5.50 mm pitch.

What the 60 A Rating and 5.50 mm Pitch Mean for Your Board

60 A per contact is not a derated signal current — it is the full rated load for a power blade.

Lifecycle and Sourcing — Active Production, No Cross-Reference

This plug accepts the matching EXTreme Ten60Power receptacle housing (female blade terminals) from the same 46437 series. The press-fit termination eliminates the need for soldering, which reduces assembly steps and allows rework in backplane applications.

Frequently asked questions

What connector mates with the 0464379208?

The 0464379208 mates with the matching EXTreme Ten60Power receptacle housing from the same 46437 series — a female blade terminal housing that accepts the same 5.50 mm pitch, single-row layout. Both halves must be from the same series to ensure proper keying and current rating.
