The Molex 0755860007 is a 68-position SAS Mini receptacle from the iPass PCI Express 75586 series, designed for internal high-speed serial data interconnects in storage and server backplanes.
Board Layout and Termination Notes
The 68 positions are arranged in a dual-row configuration typical of the SAS/SATA internal interface standard, so the footprint matches the standard SAS connector pad pattern. The board guide (a pair of plastic alignment posts) takes the shear load during plug insertion, protecting the SMT solder joints from stress that could crack them over repeated mate cycles. Tape & Reel packaging is standard for automated pick-and-place; the Cut Tape option suits prototype or low-volume builds.
This is the receptacle (female) half of the iPass PCI Express interface. It mates with the corresponding iPass plug (male) connector from the same 75586 series.
