Molex Milli-Grid 79107 receptacle, 0791077011, 24 positions, 2 rows, 2.00mm pitch, through-hole solder termination, gold mating finish, 1A, 125V, -55°C to 125°C, black thermoplastic housing, ROHS3 compliant.
| Parameter | Value |
|---|---|
| Series | Milli-Grid 79107 |
| Type | Female Socket |
| Mounting | Through Hole |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Voltage rating | 125V |
| Current rating | 1A |
| Operating temperature | -55°C ~ 125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.175\" (4.45mm) |
| Insulation material | Thermoplastic, Glass Filled |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Termination | Solder |
| Applications | Automotive, General Purpose, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 24 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.118\" (3.00mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 74.8µin (1.90µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 0791077011: The through-hole solder termination with 0.118" post length gives a solid mechanical anchor for cable strain or board stacking — no press-fit tooling needed, just a wave solder bath.
This receptacle mates with Milli-Grid 79107 series pin headers of matching pitch and position count — 24 positions, 2 rows, 2.00mm row spacing.
This receptacle mates with a Milli-Grid 79107 series pin header of matching pitch (2.00mm), row spacing (2.00mm), and position count (24). The push-pull interface means the header provides the retention.
The mating pitch is 2.00mm (0.079") with a row spacing also at 2.00mm (0.079"). This is a standard Milli-Grid footprint for dense board-to-board or cable interconnects.
Yes, it is ROHS3 compliant, meeting the latest EU directive on restricted substances.
