0872644452 — Molex product photo
Molex

Molex 0872644452 Milli-Grid 44-Pin Right-Angle Receptacle

MPN0872644452
Active

Molex Milli-Grid 87264 series, 44-position dual-row receptacle, 2.00 mm pitch, through-hole right-angle, gold-plated mating contacts, rated 1 A per contact at 125 VAC, -55°C to 105°C operating range.

$6.0600Ref. price · indicative, final on quote
0872644452 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

0872644452 Technical Specifications
ParameterValue
SeriesMilli-Grid 87264
GenderFemale Socket
Mounting typeThrough Hole, Right Angle
Connector typeReceptacle
Fastening typePush-Pull
Voltage rating125VAC
Current rating1A
Operating temperature-55°C ~ 105°C
Insulation colorBlack
Insulation height0.157\" (4.00mm)
StyleBoard to Board or Cable
PackageTube
TerminationSolder
ApplicationsAutomotive, General Purpose, Telecommunications
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions44
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact length - post0.100\" (2.54mm)
Contact finish - matingGold
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Board-Edge Routing with the 44-Pin Right-Angle Receptacle

The 0872644452: This 44-position receptacle sits in the Milli-Grid 87264 series with a 2.00 mm pitch that sets the board footprint for compact routing — two traces between pads on standard 1 oz copper are feasible, keeping the signal layer dense.

ROHS3 compliant, which covers the full substance restriction scope for EU and global markets.

Termination is solder-only — through-hole tails 0.100 inch (2.54 mm) long accept wave or hand solder. Post-plating is tin (100 µinch), which wets well with standard lead-free solder alloys.

Frequently asked questions

What is the pitch of Molex 0872644452?

2.00 mm (0.079 inch) pitch on both the mating interface and row spacing.

How many pins does 0872644452 have?

44 positions, dual-row, all loaded.

Is 0872644452 a right-angle connector?

Yes, through-hole right-angle orientation — the body sits parallel to the PCB.

Is 0872644452 RoHS compliant?

Yes, ROHS3 compliant.
