Molex C-Grid III 90120 series, 0901200765 – 5-position, single-row, unshrouded breakaway header, 0.100" (2.54mm) pitch, through-hole solder termination, gold-plated mating contacts, UL94 V-0 housing.
| Parameter | Value |
|---|---|
| Series | C-Grid III 90120 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Operating temperature | -55°C ~ 125°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.098\" (2.50mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | Automotive, General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Overall contact length | 0.478\" (12.15mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.266\" (6.75mm) |
| Contact finish thickness - post | 118.1µin (3.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
It is ROHS3 compliant.
This unshrouded header mates with C-Grid III crimp receptacle housings and IDC socket connectors that accept 2.54mm pitch. In vibration-prone applications, a secondary locking housing or wire-retention feature should be specified on the receptacle side. Termination is through-hole solder.
The pitch is 0.100" (2.54mm). This is a standard grid pitch, so it mates with any 2.54mm-pitch C-Grid III receptacle or industry-standard socket.
Yes, the 0901200765 is ROHS3 compliant. The tin plating on the solder tails is lead-free, and the housing material contains no restricted substances above threshold limits.
Availability and current pricing confirmed at quote time — submit an RFQ for this exact order code.
