The Molex 0903273312 is a 12-position IDC receptacle from the Picoflex PF-50 90327 series, designed for mass-termination to 26-28 AWG ribbon cable. The white housing is keyed and polarized to prevent mis-mating with the matching Picoflex header. The free-hanging (in-line) mounting style suits point-to-point cable assemblies where a board-mounted header is the mating half.
Contact Plating and Wire Range
The female socket contacts use a palladium-nickel finish with a thickness of 24.0µin (0.61µm). The 26-28 AWG wire range covers the most common ribbon cable gauges for signal-level interconnects.
