Molex Nano-Fit 1054311406, 6-Position 2.50mm SMT Header, 4A
MPN1054311406
Active
Molex Nano-Fit 1054311406, 6-circuit 1-row SMT header, 0.098" (2.50mm) pitch, male pin, latch holder. Rated 4A per circuit at 250VAC; gold on mating face, tin on solder tail. Operating range -40 to 115 °C. UL94 V-0 LCP housing, tape and reel.
$3.3735Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Nano-Fit 105431 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 250VAC |
| Current rating | 4A |
| Operating temperature | -40°C ~ 115°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.382\" (9.70mm) |
| Insulation material | Liquid Crystal Polymer (LCP) |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Features | Pick and Place, Solder Retention |
| Package | Tape & Reel (TR) |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.098\" (2.50mm) |
| Positions | 6 |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 30.0µin (0.76µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Frequently asked questions
What is 1054311406's listed style on this component line?
The listed style is Board to Cable/Wire — this header mates with a harness-side Nano-Fit receptacle housing to complete a wire-to-board power or signal interconnect.
What compliance documentation does Molex provide for 1054311406?
UL94 V-0 flammability is the only compliance rating cited in the listing. Confirm RoHS/REACH status and any applicable industrial safety certifications against the official Molex product drawing or a current REACH/RoHS declaration.
