Molex 1511181104

1511181104 Molex Milli-Grid Header, 2.00 mm, 4 Pos, SMT

MPN 1511181104
Active

Molex Milli-Grid 151118 series, 1511181104, a 4-circuit, 2-row, shrouded SMT header on 2.00 mm pitch, gold-plated mating contacts, rated 2 A per circuit at 125 VAC, with a detent lock and glow-wire compliant housing.

$1.2200 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesMilli-Grid 151118
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1511181104 key specifications
ParameterValue
SeriesMilli-Grid 151118
TypeMale Pin
MountingSurface Mount
Connector typeHeader
Fastening typeDetent Lock
Voltage rating125VAC
Current rating2A
Operating temperature-55°C ~ 105°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.252\" (6.40mm)
Insulation materialLiquid Crystal Polymer (LCP), Glass Filled

All specifications

1511181104 additional specifications
ParameterValue
Mated stacking heights8.14mm, 8.35mm
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTube
FeaturesBoard Guide, Glow Wire Compliant, Pick and Place
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions4
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact finish - matingGold
Contact length - mating0.142\" (3.60mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating1.97µin (0.050µm)

Product details

2.00 mm pitch, 4 circuits, shrouded SMT header

The 1511181104 is a 4-position, 2-row header from the Milli-Grid 151118 series. The gold flash handles moderate mating cycles without fretting corrosion in controlled environments.

Two stack heights from one part number

This header supports mated stacking heights of 8.14 mm and 8.35 mm, depending on the mating receptacle. That lets a single BOM line cover two board-to-board gaps. The insulation height is 0.252" (6.40 mm), and the mating pin length is 0.142" (3.60 mm). The SMT footprint keeps the component within the board profile, with no through-hole tails to interfere with backside routing.

Glow wire and flammability — compliance built in

That qualification is a direct pass for appliance, lighting, and HVAC control boards — no separate glow-wire test needed at the board level.
