Molex SL 171973 series, Board to Cable/Wire Header, 4 circuits, 0.100" (2.54mm) pitch, single-row, SMT, shrouded 4-wall, latch holder, tin-plated male pins, 3 A, 250 V, UL94 V-0, black LCP housing.
| Parameter | Value |
|---|---|
| Series | SL 171973 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 250V |
| Current rating | 3A |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.465\" (11.80mm) |
| Insulation material | Liquid Crystal Polymer (LCP) |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tube |
| Features | Polarizing Key |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 4 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.240\" (6.10mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 1719730004: This is a 4-position single-row header from Molex's SL 171973 series, designed for board-to-cable/wire applications. Rated 3 A per contact at 250 V, with tin-on-tin contact finish (100 µin on both mating and post sides).
Insulation height is 0.465" (11.80 mm), giving the latch mechanism room to engage.
This header mates with a SL series crimp receptacle housing (e.g., Molex 70066 or similar 4-position single-row housing) that accepts the matching crimp terminals. The latch holder on the header engages the latch on the receptacle.
