Molex 1727040160 — D-Sub Cable Assemblies

Molex 1727040160 FCT D-Sub Plug, 9 Pos, Solder Cup, 5A

MPN1727040160
Active

Molex F, FCT 172704 series D-Sub plug, 9 positions, 2 rows, solder cup termination, 5A, gold-plated brass contacts, steel shell with grounding indents.

$3.8400Ref. price · indicative, final on quote
Molex 1727040160 datasheet (PDF)
RoHSROHS3 Compliant
SeriesF, FCT 172704
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1727040160 key specifications
ParameterValue
SeriesF, FCT 172704
TypeSignal
MountingFree Hanging (In-Line)
Connector typePlug, Male Pins
Current rating5A
Wire gauge20 AWG
Shell size, connector layout1 (DE, E)
Operating temperature-55°C ~ 125°C
ColorWhite
Contact materialBrass
Dielectric materialPolybutylene Terephthalate (PBT)
Shell material, finishSteel, Tin Plated

All specifications

1727040160 additional specifications
ParameterValue
PackageBulk
FeaturesGrounding Indents
TerminationSolder Cup
Contact finishGold
Flange featureHousing/Shell (Unthreaded)
Rows2
Positions9

Product details

D-Sub Plug for Cable Assembly — 9-Position Solder Cup

The Molex 1727040160 is a standard-density D-Sub plug with 9 positions arranged in 2 rows, from the F, FCT 172704 series.

Wiring and Termination — Solder Cup for 20 AWG

Termination is solder cup — each contact has a cup that accepts stripped 20 AWG wire. The solder joint is then insulated with heat-shrink or the backshell cavity. The unthreaded housing/shell flange accepts a standard D-Sub backshell or hood with jackscrews for mating retention.

Operating Range and Shielding

Frequently asked questions

Is the Molex 1727040160 compatible with standard D-sub hoods?

Yes. The 1727040160 uses a standard DE-9 (E) shell layout with an unthreaded housing/flange, so it accepts any standard D-Sub backshell or hood designed for a 9-position plug. The hood's jackscrews provide the mating retention.

What is the wire gauge for Molex 1727040160?

The solder cup termination is designed for 20 AWG wire. For a reliable solder joint, use a wire with a stripped length that fills the cup without excess solder wicking up the strands.
