Molex 1731091168 — D-Sub Cable Assemblies

Molex 1731091168 D-Sub Receptacle, 9-Pin, 5A, Through-Hole

MPN1731091168
Active

Molex FCT 173109 D-Sub receptacle, 9 positions, 2 rows, female sockets, 5A, through-hole solder, steel shell with tin plating, UL94 V-0.

$10.3100Ref. price · indicative, final on quote
Molex 1731091168 datasheet (PDF)
SeriesF, FCT 173109
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1731091168 key specifications
ParameterValue
SeriesF, FCT 173109
TypeSignal
MountingThrough Hole
Connector typeReceptacle, Female Sockets
Current rating5A
Contact formMachined
Shell size, connector layout1 (DE, E)
Operating temperature-55°C ~ 125°C
ColorWhite
Contact materialCopper Alloy
Primary materialMetal
Dielectric materialPolyester, Glass Filled

All specifications

1731091168 additional specifications
ParameterValue
Shell material, finishSteel, Tin Plated
Material flammability ratingUL94 V-0
PackageBulk
TerminationSolder
Flange featureHousing/Shell (Unthreaded)
Rows2
Positions9

Product details

D-Sub Receptacle for Panel and PCB Mount

The Molex 1731091168 is a 9-position D-Sub receptacle with female sockets, part of the FCT 173109 series. It uses machined copper alloy contacts rated for 5A per circuit, terminated via through-hole solder to the PCB. The steel shell carries a tin-plated finish, and the glass-filled polyester insulator meets UL94 V-0.

This receptacle mates with a standard E shell size D-Sub plug with male pins. The housing has unthreaded mounting holes for panel or bracket attachment.

Frequently asked questions

What is the mating connector for 1731091168?

The 1731091168 mates with a standard DE-9 (E shell size) D-Sub plug carrying male pins. The shell size and layout are 1 (DE, E) per the connector layout specification.

What is the pinout of 1731091168?

The 1731091168 is a 9-position D-Sub receptacle with the standard DE-9 pin arrangement. Pin 1 is at the top-left when viewing the mating face with the wider row at the bottom.
