Molex 1731091172 — D-Sub Cable Assemblies

Molex 1731091172 FCT D-Sub Receptacle, 9-Position, 5A

MPN1731091172
Active

Molex F, FCT 173109 D-Sub receptacle, 9 positions, 2 rows, 5A, through-hole, solder termination, steel/tin shell, UL94 V-0.

$8.1800Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesF, FCT 173109
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

1731091172 key specifications
ParameterValue
SeriesF, FCT 173109
TypeSignal
MountingThrough Hole
Connector typeReceptacle, Female Sockets
Current rating5A
Contact formMachined
Shell size, connector layout1 (DE, E)
Operating temperature-55°C ~ 125°C
ColorWhite
Contact materialCopper Alloy
Primary materialMetal
Dielectric materialPolyester, Glass Filled

All specifications

1731091172 additional specifications
ParameterValue
Shell material, finishSteel, Tin Plated
Material flammability ratingUL94 V-0
PackageBulk
TerminationSolder
Flange featureHousing/Shell (Unthreaded)
Rows2
Positions9

Product details

9-Position D-Sub Receptacle for Signal Interconnects

The Molex 1731091172 is a 9-position D-Sub receptacle from the F, FCT 173109 series, designed for standard-density signal interconnects. It uses machined copper alloy contacts rated 5A per circuit, with a steel shell finished in tin plating.

Shell Size and Mating Compatibility

This receptacle uses shell size 1, connector layout DE (E), which is the standard DB-9 footprint. It mates with any standard 9-position D-Sub plug (male) having the same shell size and layout. The housing includes an unthreaded flange for mounting with screws or jack-screws — the mating plug typically carries the threaded insert or screw-lock hardware. The 2-row arrangement with 9 contacts follows the classic DB-9 pinout: 5 pins in the top row, 4 in the bottom.

Through-Hole Solder Termination

This gives a mechanically robust joint compared to surface-mount, important for a connector that sees mating/unmating forces. The machined contact form provides consistent solder-wetting and a reliable gas-tight joint after reflow or hand-soldering.

Frequently asked questions

Is 1731091172 a DB9 connector?

Yes. The shell size 1, layout DE (E) corresponds to the standard DB-9 footprint — 9 positions in a D-shaped shell. It mates with any standard 9-position D-Sub male plug.

What is the pinout of Molex 1731091172?

The pinout follows the standard DB-9 female receptacle arrangement: 5 contacts in the top row (positions 1-5) and 4 contacts in the bottom row (positions 6-9). The exact signal assignment depends on the application (RS-232, RS-485, etc.) and is defined by the system designer.

Is 1731091172 RoHS compliant?

Yes, it is ROHS3 compliant, meeting the latest EU restriction of hazardous substances directive.

Where can I buy 1731091172?

This part is sourced to order through independent distribution. Submit an RFQ for current pricing and availability — confirmed at quote time.
