Molex 1731091176

Molex 1731091176 D-Sub Receptacle, 9-Position, 5A

MPN 1731091176
Active

Molex F, FCT 173109 series D-Sub receptacle, 9 positions, 2 rows, female sockets, through-hole solder, 5A, steel/tin shell, UL94 V-0.

$8.7900 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
SeriesF, FCT 173109
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1731091176 key specifications
ParameterValue
SeriesF, FCT 173109
TypeSignal
MountingThrough Hole
Connector typeReceptacle, Female Sockets
Current rating5A
Contact formMachined
Shell size, connector layout1 (DE, E)
Operating temperature-55°C ~ 125°C
ColorWhite
Contact materialCopper Alloy
Primary materialMetal
Dielectric materialPolyester, Glass Filled

All specifications

1731091176 additional specifications
ParameterValue
Shell material, finishSteel, Tin Plated
Material flammability ratingUL94 V-0
PackageBulk
TerminationSolder
Flange featureHousing/Shell (Unthreaded)
Rows2
Positions9

Product details

9-Position D-Sub Receptacle, Through-Hole Solder

The Molex 1731091176 is a 9-position D-sub receptacle from the F, FCT 173109 series, fitted with female machined signal contacts in a 2-row layout. This is the standard DE-9 (E shell size) footprint — the same mechanical interface used on RS-232 ports, industrial machine I/O, and instrumentation panels.

What the 5 A Rating Means for Signal vs Power Duty

5 A per contact is the standard signal-level current for a machined-contact D-sub at this density. The 9-position layout keeps contact-to-contact spacing generous enough that the current limit is set by the contact itself, not by temperature rise in the dielectric.

Mating and Shell Compatibility

The unthreaded housing accepts a standard D-sub backshell kit (screw-lock or slide-lock); the 4-40 threaded inserts on the mating plug are not present on this receptacle side, so the cable-side hardware provides the locking force. Shell size 1 (DE, E) is the same footprint used across the FCT 173109 series for all 9-position variants.
