9-Position D-Sub Receptacle from the FCT 173109 Series
The Molex 1731091184 is a 9-position D-Sub receptacle from the FCT 173109 series, designed for through-hole solder termination to a PCB.
Shell Size and Mating Compatibility
This receptacle uses shell size 1 (DE, E), the standard DE-9 footprint. It mates with any standard 9-position D-Sub plug (male) having the same shell size — look for the DE-9 or DE, E designation on the mating half. The unthreaded housing shell accepts a standard D-Sub locking mechanism; for vibration-resistant applications, pair it with a plug that has threaded inserts and use jackscrews or slide locks (not included).
Termination is solder bucket to through-hole PCB — the machined contacts accept soldered wire or direct PCB solder. The two-row layout with 9 positions (5 on top, 4 on bottom) follows the standard DE-9 pinout. Mounting is through-hole only; the unthreaded flange allows panel mounting with M3 hardware or snap-in clips, but no board locks are present, so mechanical retention relies on the solder joints and any added hardware.
The dielectric is polyester, glass filled, rated UL94 V-0. The shell is steel with tin plating. Contact material is copper alloy — machined, not stamped, which gives consistent contact resistance across mating cycles.
